Save chemical and create a unique experience with the Bubblizer Arch.

The Bubblizer Arch is designed to dispense foam onto the whole vehicle while using less chemical and able to rinse off easier. Optional custom graphics and LED light kit to illuminate the foam creates an eye attracting arch that will keep customer entertained and coming back for more. This stainless steel arch includes a stainless steel tank that holds the liquid above the car. Once a blower is turned on, the arch produces foam to dispense soap, wax or protectants all over the vehicle. 96” Clearance.

  • Stainless Steel arch with Stainless Steel tank
  • Bubblizer produces a wet bubbly foam that uses less chemical and easier to rinse off.
  • The Bubblizer includes tank that holds the liquid above the car and you simply turn on a blower to produce foam.
  • One size fits all with 96″ Clearance
  • Can be used to dispense soap, wax or protectants
  • Requires a 110v circuit from Tunnel controller to power up the blowers 15 amps

LED Light Colors Available:

  • Blue
  • Red
  • Yellow

BubblizerArch_web

EconoArch

The Ultimate Economical Application Arch Solution!

  • Stainless steel arch serves as both structure and solution manifold
  • Comes complete with header, two legs and all hardware for installation including anchor bolts
  • All nozzle kits come complete with any hardware necessary for adapting to basic arch
  • Tunnel wiring is virtually eliminated by using the appropriate solution pump
  • Solution pumping station not included
  • Requires a single computer function

EconoArchesBrochure

Add Your Branding to this Functional Arch

The Graphic Arch is a decorative stainless steel arch that allows the operator the flexibility to select graphics (basic or custom) to aid in the sales of extra services and products. The Graphic Arch has a built in 1 1/2” tubular stainless steel with eleven nozzles and can be fitted with various nozzle kits to deliver:

  • Foam
  • Presoak
  • Drying aids
  • Clear Coat
  • High Pressure Rinse
  • Flood Arch
  • Simple Entrance Arch

This 96” arch allows custom graphics all around the arch. Custom graphics helps market your carwash by bringing attention to a value added service. The custom graphics can also tie your carwash together making it a cohesive tunnel.

Market your new profit making center with custom, eye attracting graphics!

  • Decorative stainless steel arch comes complete with suspended manifold similar to the versa arch
  • Suspended manifold is neatly hidden out of view to maximize appearance
  • Select appropriate nozzle kit to customize your Graphic Arch
  • Solution Pumping Station is not included
  • Requires a single computer function
  • Basic graphics included
  • Custom graphics available at additional cost
  • Fresh Water Nozzle
  • Chemical Solution Nozzle
  • Spot Free Nozzle
  • Soap Foamer Nozzle
  • Uses fresh water
  • Approved for use with a 1/2″ ARO solution pump – not included
  • Approved for use with a Flowjet Solution pump – not included
  • Approved for use with a Dosatron Solution Dispenser – not included
  • Requires a Spot Free Generator & Pump

GraphicArches_web


Upgrade your tunnel look to a new modern sleek style with LED Backlit Horizon Arches!

The 96″ Horizon Arches™ by Coleman Hanna Carwash Systems brings the internal appearance of the car wash tunnel to a new level while enabling the operator to add additional services and sources of revenue! The arches, housed in high quality stainless steel construction, are backlit with lexan panels that allow custom graphics and branding that is easily replaced. Provide your custom graphics or allow our expert design team to craft your dream arch. Also standard is LED tube lighting around the inside of the arch to further enhance the modern appearance and improve your customer experience.

The LED tube light comes standard in:

  • Red
  • Green
  • Yellow
  • Blue

The Horizon Arch™ is so versatile that the single arch can be used for:

  • Spraying
  • Applying Conditioners
  • Administering Polishing Chemicals
  • Rinsing

For the ultimate revenue enhancement add the 5 Step Sun Seal® Ultimate Car Care Process to your tunnel. This space saving design allows tunnels to easily add a dry and polish module to allow higher price and value wash packages. By simply adding one step or all five, operators create a higher value of the car wash by making the car cleaner, drier, and shinier.

Satisfy customers and drive them to purchase higher wash packages!

Step 1: Wall of Foam Conditioners

IMG_0182

Loosens road film and dirt from the vehicle’s surface preparing a clean surface for polishing. Foaming generators provides an even application.

Step 2: Triple Foam Conditioner

IMG_0326

Triple Foam Conditioner provides extra cleaning power when applied before friction elements. This intense clean and colorful display entices the customer to purchase. Triple Foam is a customer favorite additional service and will drive up revenue per wash!

Step 3: Sun Seal® Ultimate Vehicle Surface Protectant

IMG_2251_edited

Sun Seal® Ultimate Vehicle Surface Protectant provides the highest quality shine that appears to be hand waxed. This popular service seals in the protection and shields from the ultra violet properties of the sun and year-round elements.

Step 4: Wall of Water

IMG_0202

Ensure a fully rinsed vehicle by using a full encompassing Wall of Water. The waterfall trough provides a pleasing and high performance rinse. Make sure all chemicals and polishes are rinsed!

Step 5: Shammy Shine

IMG_0233

The Shammy Shine is a product that is new technology to your customers and provides state of the art perception by providing a hand dry finish with no labor while further enhancing the sheen of the vehicle.

Custom Graphics Samples

HorizonArches_brochure


Image Arches can be used for a variety of applications including spraying, trough, wall of foam, and rinsing.

This 96” arch is constructed of stainless steel like the Versa Arch but has room on the sides for identifying the step. The graphic clearance on each side is about 3″ which allows for simple labeling of the application type. This graphic area provides a marketing tool to help sell a specific service in the wash. These arches can be used for dual functions.

  • Rinse
  • Soap Foamer
  • Clearcoat
  • Rinse Arch with Soap Foamer
  • Final Rinse and Drying Agent
  • Clear Coat and Drying Agent

  • One Size fits all with 96″ Clearance.
  • All arches listed are stainless construction with easy-access panels.
  • Includes check valves on each nozzle and a single solenoid valv.
  • Single function arches will have nozzles oriented at 90° to the vehicle.
  • Dual function arches will have one set of nozzles at 90° and the other set will be at 45°.
  • Specify graphic type and color at time of purchase.
  • Custom graphics available at an additional cost.
  • Solution Pumping Station is not included.

  • Uses fresh water.
  • Approved for use with a 1/2″ ARO Solution pump – not included.
  • Approved for use with a Flowjet Solution pump – not included.
  • Approved for use with a Dosatron Solution Dispenser – not included.
  • Requires a Spot Free Generator & Pump.


PivotArch

Ensure full coverage clean with the economical Pivot Arch!

The Pivot Arch is a versatile multi-function arch with pivoting nozzles to allow full coverage of the vehicle. This arch can be utilized as both a high pressure rinse or a low pressure solution applicator. The stainless steel and manifold design are high quality and can withstand harsh chemical products. The 3”x 3” arch design construction allows more space
for marketing the product.
  • Pivots 90 degrees to ensure full coverage on front and rear of vehicle.
  • New tighter nozzle pattern for better vehicle coverage.
  • Can be utilized as both a high pressure wash/rinse or a low pressure solution applicator.
  • Wear resistant blocks promote easy pivot action and long life.
  • Can upgrade to include a foamer with low pressure application.
  • Stainless steel and manifold design will tolerate the harshest chemicals.
  • 3×3 stainless steel frame for increased strength and longevity.

PivotArch_web

UniversalArch

Save space in your tunnel by adding the widely adaptable Universal Arch!

The Universal Arch provides the ultimate durable multi-functional arch solution for your tunnel. This arch can be utilized for any application including: Multiple Chemical applicators, Wall of Foam, CTA, Rain Manifolds, Mirror Rinse. This space saving design allows multiple uses on one arch. The 3”x 3” stainless steel frame allows more space for marketing the product as well as providing a sturdy foundation.
  • Easily converts to any type of application:
    – Multiple Chemical Applicators
    – Wall of Foam
    – CTA
    – Rain Manifolds
    – Mirror Rinse
  • Can apply both chemical and rinse.
  • Allows multiple uses on just one frame saving tunnel space and reduces cost.
  • 3×3 stainless steel frame for increased strength and longevity.

UniversalArch_web

Hanna’s Versatile Application Arch

The Hanna Versa Arch is the perfect blend of form and function. The solution manifold is constructed from 1 1/2” electro-polished tubular stainless steel formed in the shape
of an arch. The Versa Arch can be fitted with various nozzle kits to deliver foam, presoak or finishing chemicals like drying aid or clear coat. The Versa Arch can also be used as a high pressure rinse or flood arch. The Versa Arch offers the car wash operator the flexibility to change with your business needs.

  • 1 1/2” Tubular Stainless Steel
  • Electro polished finish
  • Eleven welded and threaded nozzle points
  • Water feed at three points bottom left and right and top center
  • Vehicle Clearance – 96” (243.8 cm)
  • Width – 124” (315 cm)
  • Foaming Applicator
  • Pre Rinse/Final Rinse
  • Cool Down
  • Clear Coat
  • Drying Aid
  • Spot-Free Rinse
  • High Pressure Rinse
  • Flood Rinse
  • One Size fits all with 96″ Clearance
  • Stainless steel arch serves both as structure and solution manifold
  • Basic arch comes complete with header, two legs and all hardware for installation, including anchor bolts
  • All nozzle kits come complete with any necessary hardware for adapting to the basic arch
  • Tunnel wiring is virtually eliminated by using the appropriate solution pump
  • Solution Pumping Station is not included
  • Fresh water nozzle kit includes solenoid valve for on/off activation
  • All high volume and high pressure nozzle kits require high pressure pumping equipment
  • High pressure pumping equipment not included
  • Requires a single computer function
  • Electro-Polish Finish
Available in Red, Yellow, Blue and Green, the Versa Arch Light Kit is the perfect choice to bring attention to your car wash and grow your sales of on-line services. The LED light strand comes standard with mounting clips for your Versa Arch and does not require a power supply or flasher when used with Hanna’s Washlink Series of tunnel controllers. The Versa Arch Light Kit is available with an optional independent power supply and flasher if your tunnel controller requires. Ask your Hanna representative for help.

Features:

  • The Hanna light kit easily attaches to the Versa Arch and Rinse Curtain Arch frames.
  • Includes 22-feet of LED Flex Neon, Rectifier, 15 feet of electrical cord and mounting brackets.
  • The Hanna light kit will automatically rectify any 24VAC output to 24VDC eliminating any need for expensive power supplies or Nema enclosures.
  • Comes in a variety of colors.
  • Can be paired with existing computer functions.
  • Does not include a Versa Arch frame or nozzles.

VersaArch_web

VolcanoFoamArch_IMG_0872

Save Space and Money with the Volcano Foam Arch: The Ultimate Dual Entrance Arch and Wall of Foam Arch!

The Volcano Foam Arch combines the stainless grand entry arch and the Hanna Wall of Foam mounted in the back of the entrance arch. This attractive entry arch greets the customer and informs them of the proper way to enter the tunnel on the left side of the arch. On the right side of the arch, four LED confirmation lights confirm to the customer that the correct package they purchased is in progress. Custom wash package names included in arch.

  • Stainless Steel grand entry arch with Volcano Graphics
  • Hanna Wall of Foam mounted to back of arch
  • Four confirmation LED lights
  • Includes Custom Wash Package Names
  • One size fits all with 96” Clearance
  • Beautiful entry arch to welcome the customer to the car wash
  • Left side of arch instructs customer on proper way to enter tunnel
  • Right side shows confirmation to customer that correct package was purchased and in progress.

VolcanoFoamArch_brochure

Attract new customers and increase profits by adding the Coleman Hanna Wall of Foam Arch!

The Coleman Hanna Carwash Systems Wall of Foam Arch is a versatile multi-use foam curtain applicator. It can be used to apply foam conditioners for cleaning, foaming polish for shine and protection or a water fall arch for sealing or rinsing. When used as a foaming arch it utilizes three separate foam generators that adjust the amounts of chemical, water, and air to get the desired foam wetness and the consistency you want.

The arch comes with custom graphics that are tailored to your car wash allowing you to promote your brand, a specific use, or a new car wash package. The Coleman Hanna Wall of Foam can be mounted on an existing Versa Arch or can be mounted on the new Horizon arches.

    • One size fits all with 96″ clearance
    • Hanna Wall of Foam produces a thick creamy foam to cover the vehicle.
    • The arch includes three foam generators with Stainless Steel Manifold
    • Stainless steel arch serves both as structure and solution manifold
    • Foaming arch comes complete with header, two legs and all hardware for installation, including anchor bolts
    • The Foaming arch includes a Stainless Steel trough to evenly spread out the foam on the vehicle.
    • Tunnel wiring is virtually eliminated by using the appropriate solution pump
    • Arch includes a decal to welcome your customer to the Hanna Wall of Foam
    • Solution Pumping Station is not included
    • Total flow rate of arch will vary depending on air pressure and chemical approximately 7.4 gpm
    • Requires a single computer function
    • Optional LED light can be mounted behind foam trough to shine light thru Foam
    • Electro-Polish Finish
  • Wall of Foam Trough
  • Water Fall Trough
  • Blue LED light kit to illuminate the foam
  • Red LED light kit to illuminate the foam
  • Yellow LED light kit to illuminate the foam
  • Approved for use with a 1/2″ ARO solution pump – not included
  • Manifold with air and liquid regulators recommended for wall of foam – not included
Single Foam arches apply one color of foam to condition and protect the vehicle. Single Foam requires less equipment room space and chemicals than a triple foam arch. Add an additional revenue source for an economical value with single foaming arches.
The famous triple foam arch applies a color rich display of conditioning chemicals. Customers and even their children love the beautiful pink, yellow, and blue shades as it coats their vehicle providing an ex. This features is a great way to increase revenue per wash and add entertainment and cleaning value for the customer.

WallofFoam_web

All of our types of arches: horizon, image, graphic, and versa arches, can serve as a waterfall arch.

For a custom branded look consider using a graphic arch or image arch. To provide a modern eye-attracting look consider the backlit Horizon Arch.The most practical approach is to use a rinse curtain to apply a spot-free rinse or wax. The Rinse curtain uses gravity to produce a shower of water that provides no misting. It is the best choice in bays with a short drip space or with multiple sets of dryers. This economical rain arch or single manifold comes with up to 3 rows of precision cut holes to provide an even application of water or wax.

  • One size fits all with 96″ clearance
  • Hanna Rinse Curtain Arch includes a non-functional (no jets) versa arch frame
  • Manifold is pre-mounted to the structure header
  • Includes a nylon solenoid valve – Not recommended when used with solution pumps
  • Requires a single computer function
  • Electro-Polish Finish

WaterfallArch
