Drying Equipment

H.E.S.S. EQ Dryers

Provide a drier vehicle while using less energy with the EQ H.E.S.S. Series Dryers!

Hanna’s EQ H.E.S.S. (High Efficiency Stainless Steel) Dryers not only provides a desirable appearance, but also provides longevity and durability you would expect from the Coleman Hanna brand. The H.E.S.S. design provides the industrial strength for an extra-long life with easy to maintain appearance.

  • Stainless Steel housings are durable, corrosion resistance and attractive.
  • Hanna Stainless Steel nozzles available
  • Up to 5 dryers can be mounted on a single stainless steel arch
  • Standard 10hp TEFC motors
  • Housing rotates 360 degrees to allow fine tuning of the air stream
  • Corrosion resistant intake cone and Stainless Steel inlet screen
  • Stainless steel mounting hardware for easy maintenance and corrosion resistance
  • Powder coated steel impellor with backward curved blades are welded on both sides for durability
  • Each 10 HP blower produces 7800 CFM of air per with actual BHP of less than 9.0
  • Impellers are statically & dynamically balanced for power efficiency, smooth operation and improved motor life
  • Hanna recommends the use of Hanna Variable frequency drives to further lower electricity cost

EQ Dryers

EQDryers
Hanna’s EQ Series Dryers are all about high efficiency and low energy while keeping it easy and simple. Hanna’s take on this conventional drying system is aimed at quality of manufacture and the quantity of air flow while using the least amount of energy. Hanna’s Hi-Flow round nozzle design provides a smooth transition of air flow from the scrolled producers directly through to the vehicle surface. The most popular 10 HP producer delivers performance similar to other 15 HP producers. Hanna’s 7.5 HP EQ producers are not only efficient but provide tremendous drying power onto the vehicle sides, mirrors, and rocker panel areas. The ease of mounting and various configurations provides many operational designs to accomplish desired results. Hanna’s nozzles and plenums are designed to reduce air turbulence and increase performance. Each single frame arch can mount up to 5 producers.

  • Durable plastic housings with corrosion resistance and sound dampening features.
  • Hanna Hi-Flow Round nozzles standard.
  • Powder coated aluminum inlet cone and aluminum inlet screen.
  • Standard 10hp TEFC (15hp and metric motor frames optional).
  • Housing rotates 360 degrees to allow fine tuning of the air stream.
  • Stainless steel mounting hardware for easy maintenance and corrosion resistance.
  • Powder coated steel impellor with backward curved blades are welded on both sides for durability.
  • Each 10 HP blower produces 7800 CFM of air per with actual BHP of less than 9.0.
  • Impellers are statically and dynamically balanced for power efficiency, smooth operation and improved motor life.
  • Coleman Hanna recommends the use of Hanna variable frequency drives to further lower electricity cost.

EQDryersBrochure

EQ Dryers & H.E.S.S. EQ Dryers Brochure

Please provide an email address where we should send the download link.



Fin Dryer Attachment

Hanna’s Fin Dryer Attachment is the ideal solution for drying the side vertical surfaces of the vehicle. Hanna has offered the Fin Dryer Attachment in export markets where it is used as a primary drying component for conveyor systems that require less power consumption. This most recent version has shown excellent results when attached to Hanna’s EQ Series dryers running on as little as 10 HP.

The Fin Dryer Attachment has not only improved effective in smaller tunnels, but is also used as a finish type dryer in longer and faster moving conveyors.

Made of stainless steel for years of use it is easily fitted to either the Concorde or EQ Series blowers (both 10hp and 15hp models). The Fin Dryer Attachment uses a rugged synthetic fabric to direct air flow and protect against incident from longer non-standard mirrors. The small fabric nozzle is attached to a stainless steel manifold which allows it to be easily replaced. The Fin Dryer Attachment easily retrofits to any existing overhead Hanna EQ Dryer. The compact design only requires a 12-foot wide tunnel for installation.

Design Features:

  • Two models available – fits EQ blowers (both 10hp and 15hp)
  • Ordered as pairs
  • Stainless steel vertical manifold (Length 89-1/4” 226.7cm)
  • Contoured fabric nozzle (Length 55-1/2” 141cm)

FinNozzle

Fin Nozzle Attachment Brochure

Please provide an email address where we should send the download link.



Velocity Self Serve In Bay Hand Dryers

Blast the water off the vehicle and even floor mats. Ideal for any self serve operator looking to offer more detailing services and create a new profit center!

  • Self Serve In Bay Dryers
  • Self Serve In Bay Dryers

This high quality in bay dryer has a twin motor design and aerodynamic nozzle design to provide tremendous drying power while still being easy to use. The hand held air tool quickly blasts water off the vehicle and off clean floor mats. System includes: power pack, boom, special hose, unique nozzle, nozzle holder, and signs to encourage sales. Be the first location in your market to offer this innovative and powerful hand drying tool!

Attract more customers by offering the in bay drying with the Velocity In-Bay Blowers.

  • Twin High Output Blowers
  • Delay Timer To Eliminate False Starts
  • Air Knife Nozzle With Neo Glide Guides
  • Poly Nozzle Holster
  • Hose Nozzle Kit
  • Blue 30” x 2” Connector Hose
  • Blue 15’ x 2” Deliver Hose
  • Poly Dome
  • 180 Deg. Wall Boom # 73006 Included
  • Boom Length 5’-0”
  • Bay Sign Included
  • Meter Decal Sticker Included
  • Menu Strip Included

Self Serve In Bay Dryers

Velocity In Bay Dryers

Please provide an email address where we should send the download link.



Wind Blade

WindBlade

Save conveyor space and add additional revenue enhancing applications with this new space!

Hanna’s Wind Blade is a unique drying system designed to save conveyor space and to reduce energy costs. The Wind Blade accomplishes both goals by using proven theories. It takes less energy to move something in motion than it does an object that is in a stationary position. In other words, water is easier to move while it is still moving on the vehicle in the final rinse application than when it is stationary and lying flat on the surface of the vehicle.

By placing the Wind Blade 4’ to 5’ behind the final rinse application we are able to use the 20 HP Wind Blade to remove a very high percentage of the water from the vehicle. This allows additional EQ H.E.S.S. (high efficiency stainless steel) blowers placed closely behind the Wind Blade to finish the drying of the vehicle using much less energy and saving valuable conveyor space. Saving valuable conveyor space allows you to add other revenue generating products such as to increase your revenue and profitability and customers experience.

  • Stainless Steel housings are durable, corrosion resistance and attractive.
  • Wind Blade pivots toward front of vehicle or toward back of vehicle
  • Wind Blade helps dry the back of Trucks, vans and SUV’s
  • Standard 10 HP TEFC motors
  • Housing rotates toward vehicle at 22 degrees to help blow off the water
  • The Wind Blade comes with 2- 10 HP Stainless steel blowers
  • Stainless steel mounting hardware for easy maintenance and corrosion resistance
  • Powder coated steel impellor with backward curved blades are welded on both sides for durability
  • Each 10 HP blower produces 7800 CFM of air per with actual BHP of less than 9.0
  • Impellers are statically & dynamically balanced for power efficiency, smooth operation and improved motor life
  • Hanna recommends the use of Hanna Variable frequency drives to further lower electricity cost

WindBlade

Wind Blade Brochure

Please provide an email address where we should send the download link.



Wind Wizard

Complete the wash with an effective blower system. The Wind Wizard 2.0 comes in an on board package or as a free standing system. The programmable rotating center nozzle makes it easy and effective to dry the vehicle from both directions. The stainless steel reinforced molded housing provides greater safety and less noise.

On Board Blower

Water Wizard 2.0

  • Stainless steel re-enforced molded producer housing for greater safety and less noise
  • 10 HP TEFC motors with welded steel fans
  • Open design allows easy access
  • Dynamically balanced fan
  • Ability to dry vehicle from both directions Programmable rotating center nozzle
  • Heavy duty stainless steel safety screen
  • Includes motor starters
  • Air flow: 10 HP motor – 3,800 CFM per nozzle
  • Air speed: 155 mph

Free Standing Floor Mount

Freestanding Dryers

  • Same features as on-board blower except motor starter package is optional
  • Overall height: 127 1/2”
  • Overall width: 184 1/2”
  • Maximum clearance: 90” High X 115” wide
